Revit 2013 not (yet) supported! Material > Cut Pattern. (Line weight: Pen 1). Filled regions. (Custom line weight). Material > Surface Pattern. (Line weight: Pen 1) ...
Respect the Hierarchy

Scope: Project

Scope: View

(room fill types are set globally)

Room Fills

Scope: Element in View

(hatch types are set globally)

Filled / Masked Region

(line styles are set globally)

Detail Lines

(line styles are set globally)

Line Work Tool Element Overrides > Halftone

(line styles are set globally)

Silhouette Edges Element Overrides View Filters

„Beyond“ Line Style (phasing overrides are enabled/disabled per view)

Phasing Graphic Overrides Cut Line Styles Visibility / Graphic Overrides View Properties

Materials (Cut / Projection) Object styles Settings (Line weight, line style etc.)

© 2012 Autodesk

12

Settings

This is where you start!

© 2012 Autodesk

13

Settings: Fill Patterns Custom Hatches? Free Revit-Plugin: Hatch22! http://mertens3d.com/tools/ tools.php Revit 2013 not (yet) supported!

Material > Cut Pattern (Line weight: Pen 1) Filled regions (Custom line weight) Material > Surface Pattern (Line weight: Pen 1)

© 2012 Autodesk

14

Settings: Lines

Thinnest possible line weight: 0.025 mm

© 2012 Autodesk

15

Object Styles

© 2012 Autodesk

16

Materials: Revit 2012

© 2012 Autodesk

17

Materials: Revit 2013

http://www.aecbytes.com/tipsandtricks/2012/issue61-revit.html © 2012 Autodesk

18

Materials: Revit 2013 

Materials now draw their properties from assets:  Graphics  Shading  Surface Pattern  Cut Pattern  Appearance  Properties for:  Rendering  Realistic Visual Style  Ray Trace Visual Style  Physical  Structural Properties  Thermal  NEW!

© 2012 Autodesk

What does that mean? You can assign the same asset to multiple materials!

19

Visibility/Graphic Overrides & Cut Line Styles Revit 2012

Revit 2013

NEW!

© 2012 Autodesk

20

View Filters

NEW! More on filters later...

© 2012 Autodesk

21

2D Tools - View Specific

Only when all else fails...

© 2012 Autodesk

22

Respect the Hierarchy

Scope: Project

Scope: View

(room fill types are set globally)

Room Fills

Scope: Element in View

(hatch types are set globally)

Filled / Masked Region

(line styles are set globally)

Detail Lines

(line styles are set globally)

Line Work Tool Element Overrides > Halftone

(line styles are set globally)

Silhouette Edges Element Overrides View Filters

„Beyond“ Line Style (phasing overrides are enabled/disabled per view)

Phasing Graphic Overrides Cut Line Styles Visibility / Graphic Overrides View Properties

Materials (Cut / Projection) Object styles Settings (Line weight, line style etc.)

© 2012 Autodesk

23

Respect the Hierarchy

Scope: Project

Scope: View

(room fill types are set globally)

Room Fills

Scope: Element in View

(hatch types are set globally)

Filled / Masked Region

(line styles are set globally)

Detail Lines

(line styles are set globally)

Line Work Tool Element Overrides > Halftone

(line styles are set globally)

GOOD!

Silhouette Edges Element Overrides View Filters

„Beyond“ Line Style (phasing overrides are enabled/disabled per view)

Phasing Graphic Overrides Cut Line Styles Visibility / Graphic Overrides View Properties

Materials (Cut / Projection) Object styles Settings (Line weight, line style etc.)

© 2012 Autodesk

24

Respect the Hierarchy

Scope: Project

Scope: View

(room fill types are set globally)

Room Fills

Scope: Element in View

(hatch types are set globally)

Filled / Masked Region

(line styles are set globally)

Detail Lines

(line styles are set globally)

Line Work Tool

DETAILING AND Element Overrides EMERGENCIES ONLY! Element Overrides > Halftone

(line styles are set globally)

GOOD!

Silhouette Edges View Filters

„Beyond“ Line Style (phasing overrides are enabled/disabled per view)

Phasing Graphic Overrides Cut Line Styles Visibility / Graphic Overrides View Properties

Materials (Cut / Projection) Object styles Settings (Line weight, line style etc.)

© 2012 Autodesk

25

Respect the Hierarchy: Work Your Way Up!

Scope: Project

Scope: View

(room fill types are set globally)

Room Fills

Scope: Element in View

(hatch types are set globally)

Filled / Masked Region

(line styles are set globally)

Detail Lines

(line styles are set globally)

Line Work Tool Element Overrides > Halftone

(line styles are set globally)

Silhouette Edges Element Overrides View Filters

„Beyond“ Line Style (phasing overrides are enabled/disabled per view)

Phasing Graphic Overrides Cut Line Styles Visibility / Graphic Overrides View Properties

Materials (Cut / Projection) Object styles Settings (Line weight, line style etc.)

© 2012 Autodesk

26

The Odd Bunch: Exceptions to the Rule

© 2012 Autodesk

27

Visual Styles - An Overview

© 2012 Autodesk

29

Realistic Style

NEW! RPC objects now appear textured in realistic mode.

© 2012 Autodesk

30

Ray Trace Style 

© 2012 Autodesk

NEW! Photorealisting rendering mode  Interactive - you can move around in the model while it renders  Starts with a low resolution rendering that gradually improves  NEW! Lighting & photographic exposure settings  Available for realistic style, too

31

Ambient Shadows

© 2012 Autodesk

32

Ambient Light   

© 2012 Autodesk

Playing with the Ambient Light settings can yield differing results. 0 -100% As you increase the value, this will affect the material colour.

33

Silhouette Settings  



© 2012 Autodesk

Elevations and 3D views can be given graphic emphasis automatically. The Graphics Display tools allow the user to specify line styles to be used as overrides on the profiled edges seen in elevation and 3D views. Linework can be used to further refine the profiles.

34

Silhouettes & Shadows

© 2012 Autodesk

35

Shadow Settings 





© 2012 Autodesk

The Graphic Display Options allow you to control the shadow settings.You can control:  Sun Intensity  Ambient Light  The shadow Intensity From experience, playing down the depth of the shadows helps to pop the view. Try Sun Intensity set to 60 and Cast Shadows to around 20 to 30. 36

Background 



© 2012 Autodesk

You can set the background to:  Gradient  Sky (like in render mode) NEW!  Image (like in render mode) NEW! These backgrounds are available in:  Isometric  Perspective  Elevation NEW!  Section NEW! 37

Hardware! 

To maximise the ability to work with some of the graphic functions within Revit, ensure your graphics card can use Hardware Acceleration.

© 2012 Autodesk

38

Orient to View    



Create a section or a wall section Create a new 3d view Then from the view cube select Orient to View Pick your section and the 3d view will be oriented to the section. Free rotate as required to generate a 3d section.

© 2012 Autodesk

40

Orient to View 

Use the Orient to view tool to create Floor slices for stacking diagrams  3D details  3D sections  Explosion isometrics 



Lock the 3D view 

Use Annotation!

© 2012 Autodesk

41

Orient to View: Elevations 



One particular challenge is that glass material displays as a solid color in elevation. If you require glass to be transparent, use a combination of a 3D isometric view and the view cube to orient to an elevation of the model.

© 2012 Autodesk

42

3D Sections 

Use the section box feature to create section and plan perspectives.

© 2012 Autodesk

43

3D Sections: Understanding Poche 



The Poche material is the material colour you see when a section box is defined in a 3D view. It will only display when the level of detail is set to coarse.

© 2012 Autodesk

44

Stacking Views 

 

Use a combination of percategory-overrides and filters to generate different versions of the same isometric view Stack them on top of each other on a sheet Perhaps add some connecting detail lines on the sheet

© 2012 Autodesk

45

Stacking Views 

Stacking works well with elevations or sections (foreground / background), too. Foreground  Masking region set to custom transparency  Background 

 

Mixture of different visual styles possible Some issues in Revit 2013 with some visual styles & graphics settings when printing © 2012 Autodesk

46

Masking Regions

© 2012 Autodesk

47

Show Hidden Lines 

Allows you to display elements which are obscured by other elements

© 2012 Autodesk

48

Line-based Generic Model

© 2012 Autodesk

50

Line-based Generic Model

© 2012 Autodesk

51

2D Entourage

http://www.neubauladen.com/

© 2012 Autodesk

52

Planting

Coarse

© 2012 Autodesk

Medium

53

Fine

Planting Coarse

© 2012 Autodesk

Medium

54

Fine

Site

© 2012 Autodesk

55

Annotation

http://revitcomponents.com/

© 2012 Autodesk

56

Colour

© 2012 Autodesk

57

Typography!

© 2012 Autodesk

58

View Templates 

View Templates can include all view specific information on look and style 



NEW! Color Scheme

Great productivity boost! Create a template for each type of view  Assign template to all views of given type 

© 2012 Autodesk

60

View Templates 

NEW! If a view template is assigned to a view... ...the view will automatically update when changes are made to the view template.  ...view properties controlled by the view template are locked / disabled. 



Rule of thumb: 



Use a view template for every view type that occurs at least twice in your model.

View Templates & Visual Styles: A lot of the visual styles functionality is quite CPU-heavy  Use two view templates for these kinds of views: 

 

© 2012 Autodesk

One for working One for printing

61

Rooms Information that should already be available in your model.  Adding some colour, via Colour Fill Legends and Room Tags, to communicate the spaces use.  Making the plan punch by adding a coarse fill to the walls, and turning on shadows (but keeping them light & the sun bright). 

© 2012 Autodesk

62

Rooms Don’t forget you can use colour legends in sections views as well as plans.  The important factor is that the room volume extends from the floor finish all the way to the underside of the floor above. 

© 2012 Autodesk

63

Filters   

Control the appearance of elements based on their properties Much smarter than override by element! Filters stack! You can apply more than one filter to the same element  Move more important/specific filters settings to the top of the filter list 

© 2012 Autodesk

64

Filters

© 2012 Autodesk

65

Filters: Example

© 2012 Autodesk

66

Filters: Selection Sets NEW! Selection sets can be saved and used as filters

© 2012 Autodesk

67

Filter Hacking

© 2012 Autodesk

68

Filter Hacking

© 2012 Autodesk

69

Shared Parameters 

Make your model even smarter 

Add shared parameters to element categories where applicable 



Example: Categorize rooms according to different aspects

Use shared parameters for filtering

© 2012 Autodesk

70

Please Recycle!   

You do not want to start from scratch every time. Develop your own standards Reuse them Transfer project standards  Create your own template 

© 2012 Autodesk

71

Revit 2013: Lots of New Graphics Features

       

Materials Transparency per Category / Element Selection Sets for Use with Filters RPC Objects Rendered in Realistic Visual Style Ray Trace Visual Style Lighting & Photographic Exposure for Realistic & Ray Trace Visual Styles Gradient, Sky & Image Backgrounds for Isometric, Perspective, Section & Elevation View Templates Auto-Update

http://autodesk-revit.blogspot.com.es/2012/03/what-new-in-autodeskrevit-2013.html

© 2012 Autodesk

73

Presentation Graphics - Best Approach

     

Presentation Intent Comes First Develop Your Own Graphic Language/Style Know Your Tools Out of the Box is Not Enough If Possible, Let the Data Drive the Graphics Experiment!
